DJI Agras T40

The DJI Agras T40 Agricultural Drone is engineered for modern farming needs, combining high payload capacity with advanced spraying and spreading technologies. Its coaxial twin rotor design enhances payload capacity by 30%, allowing for a 40kg spraying load and a 50kg spreading load.

Equipped with a dual atomized spraying system, the T40 ensures uniform droplet size and efficient pesticide usage. The magnetic drive impeller pump isolates chemicals from the motor, enhancing durability and corrosion resistance.

Advanced Active Phased Array Radar and Binocular Vision systems provide 360° obstacle sensing, enabling the drone to navigate complex terrains safely. Integrated with DJI Terra, the T40 supports real-time mapping and intelligent route planning, optimizing operational efficiency.

Key Features:

• High Payload Capacity: Supports up to 40kg for spraying and 50kg (70L) for spreading applications.
• Dual Atomized Spraying System: Ensures even droplet distribution and efficient chemical usage.
• Magnetic Drive Impeller Pump: Enhances durability by isolating chemicals from the motor.
• Advanced Obstacle Sensing: 360° detection with Active Phased Array Radar and Binocular Vision.
• Integrated Mapping with DJI Terra: Supports real-time mapping and intelligent route planning.
• Foldable Design: Reduces size by 70% for easier transportation and storage.

Specifications:

• Spraying Tank Capacity: 40L
• Spreading Payload: 50kg (70L)
• Max Spray Width: 11m
• Max Spread Width: 7m
• Droplet Size: 50–300 μm
• Obstacle Sensing Range: 1.5–50m
• Operating Temperature: 0°C to 40°C
• Flight Time (Full Load): Up to 18 minutes
• Battery Capacity: 30,000 mAh
• Dimensions (Unfolded): 2800 × 3150 × 780 mm
• Dimensions (Folded): 1125 × 750 × 850 mm

In the Box:

• DJI Agras T40 Drone × 1
• Intelligent Flight Battery × 2
• Battery Charger × 1
• Remote Controller × 1
• Propeller Pairs × 4
• Spraying System Components × 1 Set
• Spreading System Components × 1 Set
• User Manual × 1
• Carrying Case × 1

Compatibility:

• DJI Terra
• DJI Agras App
• DJI D-RTK 2 Mobile Station
• DJI RC Plus Controller

Enhance your agricultural operations with the DJI Agras T40 Agricultural Drone—combining high payload capacity, advanced spraying and spreading systems, and intelligent mapping for efficient and precise farming.
